1/16" Fittings
SGE Ferrules- 1/16" Fittings
All ferrules supplied in packets of 10
Ferrule Style
|
Hole ID
|
100% Graphite
|
15% Graphite 85% Vespel
|
100% Vespel
|
Straight |
1/16" |
SG072623 |
SG072657 |
SG072684 |
Sealing Ring |
1/16" |
SG0726520 |
SG072653 |
- |
Reducing |
0.2mm |
- |
SG0726632 |
- |
0.3mm |
- |
SG072659 |
- |
|
0.4mm |
- |
SG072663 |
- |
|
0.5mm |
SG072627 |
SG072654 |
- |
|
0.8mm |
SG0272626 |
SG072655 |
- |
|
0.9mm |
- |
SG072658 |
- |
|
Reducing (Short) |
0.3mm |
- |
SG073107 |
- |
0.4mm |
- |
SG073109 |
- |
|
0.5mm |
SG072610 |
SG073111 |
- |
|
0.8mm |
SG072608 |
SG073113 |
- |
|
1.0mm |
SG072607 |
- |
- |
|
1.2mm |
SG072606 |
- |
- |
|
2-Hole |
2.0 x 0.3m |
- |
SG072660 |
- |
2 x 0.4mmm |
- |
SG072662 |
- |
|
2 x 0.5mm |
- |
SG072664 |
- |
|
0.5 & 0.3mm |
- |
SG0726640 |
- |
|
0.4 & 0.3mm |
- |
SG0726641 |
- |
|
0.5 & 0.4mm |
- |
SG0726642 |
- |
|
3-Hole |
3 x 0.4mm |
- |
SG072665 |
- |
No-Hole (Blank) |
- |
- |
SG072661 |
SG0726841 |
No Hole (Short & Blank) |
- |
- |
SG073105 |
- |
(100% Vespel Ferrules)
SilTite™ Metal 1/16" Ferrules
Description |
Pack Contents |
Part No. |
1/16" SilTite Starter Kit |
10 Ferrules & 2 Nuts |
SG073203 |
Replacement 1/16" SilTite Ferrules |
10 Ferrules |
SG073223 |
Replacement 1/16" SilTite Nuts |
5 Nuts |
SG073225 |
